High Light Efficiency High Voltage 54-60V SMD 7070 White LED CHIP

Name: High Light Efficiency High Voltage 5460V SMD 7070 White LED CHIP
Brand: HuanYu Dream
Price: 1 USD

Wholesale High Light Efficiency High Voltage 54-60V SMD 7070 White LED CHIP from china suppliers

Brand Name : HuanYu Dream

Model Number : HY-7070W40-20C1B-10W

Certification : Rohs

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T,Paypal,Ali Pay

Supply Ability : 200KKpcs/Month

Delivery Time : 7-9 Work Days

Packaging Details : 4000pcs/Reel

Type : High Efficiency 7070 SMD LED

Current : 150mA

Voltage : 54-60V

Power : 10W

Color : 4000K

Substrate : EMC

View Angle : 120degree

Efficiency : 250-260LM/W@20mA

Contact Now

High Light Efficiency High Voltage 54-60V SMD 7070 White LED CHIP

Features

Model: 7070 Package (7x7mm Large SMD LED)

Power: 10W (requires heat sink)

Luminous Efficacy: Very High (260lm/W, but this is a low-current test value and will decrease under full load)

Voltage: High Voltage (54-60V, internal multi-chip series structure)

Application: High-end professional lighting, requires a dedicated driver.

Product Specifications

Attribute	Value
Type	High Efficiency 7070 SMD LED
Current	150mA
Voltage	54-60V
Power	10W
Color	4000K
Substrate	EMC
View Angle	120degree
Efficiency	250-260LM/W@60mA

Technical Specifications

Color	CCT(k)	VF	IF(mA)	CRI	Luminous Efficiency(lm/W@20mA)	Part number
Daylight White	4000	54-60	150	70	250-260	HY-7070W40-20C1B-10W

Product Images

High Light Efficiency High Voltage 54-60V SMD 7070 White LED CHIP

Application

1.Large-space lighting: high-bay lighting for factories, warehouses, and gymnasiums.

2.Outdoor lighting: streetlights and tunnel lights.

3.Professional lighting: plant growth lights and high-end commercial lighting.
